FHKU John Guest

The FHKU Flowmeter is a general-purpose device; its working range can be individually defined according to its nozzle size. It is employed for measuring, regulating or metering and guarantees most precise measurement of fluid quantities. In addition, a pulse generator integrated into the flowmeter guarantees a practically unlimited useful life.

Special features: Linear inlet and outlet, compact design, great working range, depending on the nozzle diameter. Hose diameters from 3/8” (9.5mm) can be directly connected.

Keypoints

  • modular
  • JG Speedfit
  • straight flowpath

Specification

Article Number

938-75xx-x01

Flowrate

overall

0.04 - 4.22 l/min

Applications

Cleaning Machines, Heating System Filter Monitoring, Formulation and Filling, Water Filtration, Refrigerator Potable Water Dispensing, Water Filter Monitoring, Vending Machines, Soft Drink Monitoring, Water Cooling Circuit, Water Injection in Steamer, Water Injection in Oven, Beer Measurement

Output Signal

Open collector NPN

Voltage Supply

+3.8 to +24 VDC

Temperature

0°C to 65°C 32°F to 149°F

Materials

PBT 35%GF (Arnite TV4 270), VMQ (Silikon) PERTEC UP VMQ 70.501-01, EPDM O-Ring 70.503-00, PVDF, Stahl verzinkt-blau

Pressure

0.0 - 10.0 bar at 20°C 0 - 145 psi at 68°F

For samples please contact our sales team.
